BLOX Racing Remote Oil Filter Relocation Kit, Silver

The BLOX Racing BXGA-00115-SI remote oil filter relocation kit allows a compatible oil filter to be mounted away from its factory location for easier access or to accommodate a custom engine-bay layout. CNC-machined billet aluminium adapters provide the foundation for a relocation system tailored to your installation. This version is supplied in silver. Ships fast across Canada and the US.

Features

• CNC-machined billet aluminium construction.
• Engine-side block-off adapter and separate remote filter adapter.
• M20×1.5 and 3/4-16 engine-side adapter fittings included.
• Mounting bracket and screws for the remote adapter.
• Oil-line port fittings and sensor-port plugs included as listed below.
• Oil lines selected separately to suit the vehicle and mounting location.

Manufacturer-Listed Contents

• One oil filter block-off adapter.
• Two block-off adapter male fittings: one M20×1.5 and one 3/4-16.
• One oil filter relocation adapter, listed with M20×1.5 female thread.
• One oil filter fitting for the relocation adapter.
• One mounting bracket and four screws.
• Four oil-line port fittings, described by BLOX as -10AN × -8AN, with gaskets.
• Two 1/8-inch NPT oil sensor plugs.
• One AS-229 block-off adapter O-ring gasket.

Oil lines are excluded from the manufacturer's kit. An oil filter, sensors or an oil cooler are not promised as included components. Confirm the supplied fittings and your chosen hose-end combination before assembling custom lines.

Compatibility Checks

BLOX describes this as a universal-design kit for custom applications. The included adapter threads alone do not establish fitment. Verify the engine's filter mounting surface and thread engagement, the remote adapter's filter fitting and gasket land, and clearance for the adapters, filter, fittings and hoses.

Match the chosen filter's thread, sealing dimensions and operating requirements to the completed system. Do not assume the original filter can be reused without checking the remote mount. No vehicle-specific make/model fitment is guaranteed by this listing.

Specifications

• Brand: BLOX Racing
• Part number: BXGA-00115-SI
• Finish: Silver
• Adapter material: Billet aluminium
• Included engine-side thread options: M20×1.5 and 3/4-16
• Sensor plug thread: 1/8-inch NPT
• Replacement block-off O-ring designation: AS-229
• Oil lines: Not included

Installation Notes

Follow BLOX's installation guide and verify inlet/outlet routing before operating the engine. Use properly rated lines and compatible fittings, secure the remote mount, and route hoses away from exhaust heat, sharp edges and moving parts. Follow the engine builder's priming procedure, verify oil pressure and check all connections for leaks before driving.

Account for any change in system oil volume when setting the final oil level. Relocating the filter does not by itself establish an oil-cooling benefit, pressure increase or horsepower gain.

Ships fast across Canada and the US.
