GrimmSpeed Black Coated Top Mount Intercooler, 2002–2007 WRX / 2004–2021 STI | GRM090024
GrimmSpeed Thermal Dispersant Black Top Mount Intercooler for WRX and STI
The GrimmSpeed GRM090024 top mount intercooler combines a black thermal dispersant coating with a bar-and-plate core and cast aluminum end tanks. Machined connection surfaces and stainless-steel threaded inserts support a durable installation on the specified EJ-powered Subaru applications. Ships fast across Canada and the US.
Features
- Black thermal dispersant coating, distinct from the silver GRM090001 version.
- High-density bar-and-plate intercooler core.
- Cast aluminum end tanks with smooth internal contours.
- Machined throttle-body connection, flange faces and internal bores.
- Stainless-steel threaded inserts to reduce the risk of damaged aluminum threads.
- Cleaned, inspected and sealed before manufacturer shipment.
Specifications
- Brand: GrimmSpeed
- Part number: GRM090024 / 090024
- Product type: Top mount intercooler
- Core construction: Bar-and-plate
- End tanks: Cast aluminum
- Finish: Thermal dispersant black
Applications
- 2002–2007 Subaru WRX: requires a separate STI-compatible Y-pipe.
- 2004–2021 Subaru WRX STI: verify the existing Y-pipe and hose configuration.
- 2004–2008 Subaru Forester XT: requires a separate STI-compatible Y-pipe; 2004–2005 models also require an STI bypass valve and recirculation hose.
These applications do not establish compatibility with 2008+ WRX or FA20DIT/FA24 WRX models. Confirm fitment separately for engine swaps, aftermarket turbochargers and modified bypass-valve or intake connections.
Package and Installation Notes
This listing is for the black coated top mount intercooler. The Y-pipe kit and hood-scoop splitter are not included. Do not assume a replacement bypass valve, recirculation hose or complete hose-and-clamp package is supplied.
Follow GrimmSpeed's installation instructions. Check mounting alignment, hood clearance, airflow coverage from the hood scoop, hose engagement and bypass-valve sealing. Inspect the finished charge-air system for leaks. Discuss calibration requirements with your tuner for the complete modification package; no specific power gain, temperature reduction or knock-prevention result is guaranteed.
