Method Race Wheels MR701 Bead Grip – 17x9 Matte Black | 8x170 | -12mm Offset

Built for the overland enthusiast who refuses to be stopped by terrain, the Method MR701 Bead Grip is one of the most innovative off-road wheels on the market. Method’s patented Bead Grip® technology allows you to air down to pressures that previously required beadlock wheels to prevent tire debeading — giving you the traction benefits of ultra-low tire pressure without the weight, cost, or DOT complications of a true beadlock. In matte black with an aggressive -12mm offset, this 17x9 in 8x170 bolt pattern is purpose-built for Ford F-250/F-350 Super Duty trucks and similar platforms.

Key Features:

• Method Bead Grip® technology — patented inner bead shelf prevents tire debeading at ultra-low pressures without a beadlock ring
• 17x9 sizing — aggressive fitment for lifted trucks and overland builds
• -12mm offset — pushes the wheel outward for a wide, aggressive stance
• 8x170 bolt pattern — direct fitment for Ford F-250 / F-350 Super Duty
• 130.81mm center bore — hub-centric fit for Ford Super Duty applications
• Matte black finish — durable, low-glare finish suited for off-road and overland use
• Cast aluminum construction — strong, lightweight, and purpose-built for off-road demands
• DOT compliant — street legal, no beadlock ring complications

Performance Benefits:

• Bead Grip® Technology: Air down to pressures previously only achievable with beadlock wheels — more traction on rocks, sand, mud, and loose terrain without risking tire debeading
• No Beadlock Complications: DOT-compliant design means no re-torquing beadlock rings, no weight penalty, and no legal restrictions for street use
• Aggressive -12mm Offset: Pushes the wheel face outward for a wide stance that fills the fender on lifted Super Duty builds
• Hub-Centric Fit: 130.81mm center bore matches the Ford Super Duty hub for a vibration-free, properly centered fitment
• Overland-Ready Durability: Cast aluminum construction handles the impacts, flex, and abuse of serious off-road use

Specifications:

• Brand: Method Race Wheels
• Model: MR701 Bead Grip
• Part Number: MR70179087512N
• Size: 17x9
• Offset: -12mm
• Bolt Pattern: 8x170
• Center Bore: 130.81mm
• Finish: Matte Black
• Construction: Cast Aluminum
• DOT Compliant: Yes
• Sold As: Single wheel

Fitment Information:

• Ford F-250 Super Duty — 8x170 bolt pattern applications
• Ford F-350 Super Duty — 8x170 bolt pattern applications
• Note: Verify your specific year, model, and lift height before ordering. -12mm offset may require a lift and/or fender modification depending on tire size.
• Sold as a single wheel — order quantity accordingly
• TPMS: Verify TPMS sensor compatibility before installation

Installation Notes:

• Sold as a single wheel — order the correct quantity for your build
• Torque lug nuts to manufacturer specification — re-torque after first 50–100 km
• Verify TPMS sensor compatibility before installation
• Check clearance with brake calipers, suspension components, and fenders before finalizing tire size
• Hub-centric rings not required — 130.81mm CB matches Ford Super Duty hub directly

Method Bead Grip® Technology:

Method’s patented Bead Grip® technology is a machined inner bead shelf integrated into the wheel barrel that grips the tire bead mechanically at low pressures. Traditional wheels rely entirely on air pressure to keep the tire seated — drop below approximately 15 PSI and you risk the tire rolling off the bead, especially under lateral load. Beadlock wheels solve this with a clamping ring, but add weight, require regular re-torquing, and are not DOT compliant for street use. Bead Grip® delivers the low-pressure capability of a beadlock without any of those drawbacks — making it the ideal solution for overlanders who air down on the trail and drive home on the highway.

Why Method Race Wheels?

Method Race Wheels was founded by off-road racers for off-road racers. Their wheels are engineered and tested in the most demanding environments — Baja, King of the Hammers, and desert racing — before reaching the consumer market. The MR701 Bead Grip is the product of that racing heritage applied to the overland and truck enthusiast market: a wheel that performs when the terrain gets serious and looks the part on the street.

Perfect For:

• Ford F-250 / F-350 Super Duty owners building an overland or off-road rig
• Overlanders who air down on trail and want beadlock-level security without the complications
• Lifted Super Duty builds seeking an aggressive -12mm offset stance
• Off-road enthusiasts who need a DOT-compliant wheel for dual street/trail use
• Anyone upgrading from stock Super Duty wheels for improved off-road capability and appearance

Pro Tip: Pair with an aggressive all-terrain or mud-terrain tire in 35–37" sizing for the full overland build aesthetic. Verify backspacing and clearance with your specific lift kit before finalizing tire size.

Note: Sold as a single wheel. Order 4 (or 5 for a matching spare) for a complete set.
