Odyssey PC680 Powersport Extreme AGM Battery - Thin Plate Pure Lead (TPPL)

Power your build with the Odyssey PC680 Powersport Extreme AGM battery. Built with Thin Plate Pure Lead (TPPL) technology, the PC680 delivers up to twice the power and three times the service life of conventional batteries, making it the go-to choice for motorsport, powersport, and high-performance street applications where reliability and power density are non-negotiable.

Key Features:

• Thin Plate Pure Lead (TPPL) AGM technology
• Up to 2x the power of conventional batteries
• Up to 3x the service life of conventional batteries
• Superior power density
• Fast-charge acceptance
• Extended shelf life
• Vibration resistant construction
• Maintenance-free sealed AGM design
• Odyssey quality and engineering

Performance Benefits:

• 2x Power: More cranking power than conventional AGM or flooded batteries
• 3x Service Life: Significantly longer lifespan reduces replacement frequency
• Fast Charging: Accepts charge faster than conventional batteries
• Vibration Resistant: Handles the harsh vibration of motorsport and powersport applications
• Long Shelf Life: Holds charge longer during storage
• Lightweight: Compact, lightweight design for weight-sensitive builds

Specifications:

• Brand: Odyssey Battery
• Part Number: PC680
• SKU: ODS-AGM16L
• Technology: Thin Plate Pure Lead (TPPL) AGM
• Type: Sealed AGM (maintenance-free)
• Weight: 14.5 lbs
• Barcode: 635241140996

Applications:

• Motorsport and track day vehicles
• Powersport vehicles (ATVs, UTVs, motorcycles, personal watercraft)
• High-performance street builds
• Race cars requiring lightweight, high-output battery
• Vehicles with high electrical demand (audio systems, multiple accessories)
• Seasonal and stored vehicles requiring long shelf life

What's Included:

• Odyssey PC680 AGM battery
• Installation instructions
• Note: Battery terminals and hardware may vary - verify terminal configuration for your application

Installation Notes:

• Verify battery dimensions and terminal configuration fit your application before ordering
• Disconnect negative terminal first when removing old battery
• Connect positive terminal first when installing new battery
• Ensure battery is securely mounted to prevent movement
• No maintenance required - sealed AGM design
• Charge with a compatible AGM-rated battery charger

Thin Plate Pure Lead (TPPL) Technology:

The PC680's performance advantage comes from its Thin Plate Pure Lead (TPPL) construction. Unlike conventional batteries that use lead alloy plates, Odyssey uses 99.99% pure lead plates. Pure lead can be made thinner than lead alloy, allowing more plates to fit within the same battery case. More plates means more surface area, which directly translates to more power and faster charge acceptance. The pure lead construction also provides superior corrosion resistance compared to lead alloy, contributing to the PC680's exceptional service life of up to three times that of conventional batteries.

AGM (Absorbed Glass Mat) Design:

The PC680 uses Absorbed Glass Mat (AGM) technology, where the electrolyte is absorbed into a fiberglass mat separator rather than being free-flowing liquid. This sealed design provides several advantages: the battery can be mounted in any orientation (except inverted), there is no risk of acid spills, and the battery is completely maintenance-free. The AGM design also provides superior vibration resistance compared to flooded batteries, as the electrolyte is immobilized within the mat. This makes the PC680 ideal for motorsport and powersport applications where vibration is a constant challenge.

2x Power vs. Conventional Batteries:

The PC680 delivers up to twice the cranking power of conventional AGM or flooded (SLI) batteries of similar size. This superior power density is a direct result of the TPPL construction - more pure lead plates means more electrochemical surface area and more power available for cranking. For high-compression engines, cold weather starting, or applications with high electrical demand, the PC680's superior cranking power provides reliable starting where conventional batteries may struggle.

3x Service Life:

The PC680 is rated for up to three times the service life of conventional batteries. This exceptional longevity is achieved through the combination of pure lead plates (which resist corrosion better than lead alloy), the sealed AGM design (which prevents electrolyte loss), and Odyssey's robust construction. While the initial cost of an Odyssey battery is higher than a conventional battery, the extended service life means fewer replacements over time, providing better long-term value. For motorsport applications where battery failure is not an option, the PC680's reliability and longevity are invaluable.

Fast-Charge Acceptance:

The TPPL construction enables the PC680 to accept charge significantly faster than conventional batteries. This is particularly important for motorsport applications where the battery may be deeply discharged between events and needs to be recharged quickly. The fast-charge acceptance also means the battery recovers more quickly from deep discharge events, such as extended periods with the engine off and accessories running. Use an AGM-compatible charger for best results.

Extended Shelf Life:

The PC680 has an exceptional shelf life, retaining its charge for extended periods during storage. This makes it ideal for seasonal vehicles, track cars that are stored between events, and any application where the vehicle may sit unused for extended periods. Conventional flooded batteries self-discharge relatively quickly and can sulfate if left discharged, requiring replacement. The PC680's superior shelf life reduces the risk of finding a dead battery after storage.

Vibration Resistance:

The sealed AGM construction and robust internal design provide exceptional vibration resistance, making the PC680 ideal for motorsport and powersport applications. Conventional flooded batteries are susceptible to damage from vibration, which can cause plate shedding and internal short circuits. The PC680's immobilized electrolyte and robust plate construction withstand the harsh vibration environments of race cars, ATVs, motorcycles, and other high-vibration applications.

Why Odyssey Battery?

Odyssey Battery is a world-renowned manufacturer of high-performance AGM batteries, trusted by professional motorsport teams, military applications, and demanding enthusiasts worldwide. Their TPPL technology represents the pinnacle of lead-acid battery engineering, delivering performance that approaches lithium batteries at a fraction of the cost and with greater reliability in extreme temperatures. Odyssey batteries are the choice of professionals who cannot afford battery failure.

Perfect For:

• Track and race cars requiring reliable, high-output battery
• Powersport vehicles (ATVs, UTVs, motorcycles, PWC)
• High-performance street builds with high electrical demand
• Seasonal vehicles requiring long shelf life during storage
• Any application where conventional battery performance is insufficient

Perfect For: Motorsport, powersport, and high-performance street builds seeking Odyssey PC680 TPPL AGM battery for superior cranking power, extended service life, and vibration resistance.

Pro Tip: Always use an AGM-compatible smart charger with the PC680 - conventional chargers may not fully charge AGM batteries and can reduce service life over time.

TPPL AGM Technology: 2x power vs. conventional batteries. 3x service life. Fast-charge acceptance. Vibration resistant. Sealed maintenance-free. 14.5 lbs.

Power your build with Odyssey PC680 - TPPL AGM technology, 2x power, 3x service life, trusted by professional motorsport worldwide.
