RaceQuip 5-Point Camlock Harness – SFI 16.1 | Pull-Down Lap | Black | 741001RQP

RaceQuip 741001RQP 5-point camlock racing harness in Black. SFI 16.1 certified. Pull-Down (PD) lap belt adjustment. Lightweight aluminium alloy camlock buckle, 3-inch polyester webbing throughout, drop-forged steel 3-bar slides, bolt-on hardware ends with wrap-around or bolt-in mounting. 7.4 lbs. Ships fast across Canada and the US.

5-Point Camlock — Configuration

This is a 5-point harness: two shoulder belts, two lap belts, and one submarine (anti-sub/crotch) strap — all five terminating at a central camlock buckle. The camlock buckle is the motorsport standard for racing harnesses — all belts insert into the central disc mechanism and release simultaneously by rotating the lever 45 degrees (left or right), allowing rapid emergency egress compared to OEM push-button or lift-latch buckles. The aluminium alloy cam buckle provides precise spring pressure and positive lever feel at the 45-degree unlatch position. The cam buckle stays attached to the right lap belt when the harness is not in use.

Pull-Down Lap Belt (PD)

The 741001RQP uses Pull-Down (PD) lap belt adjustment — you pull the lap belt ends outward and downward away from the cam buckle to tighten. This is distinct from Pull-Up (PU) lap belt designs. PD geometry is suited to fixed bucket seat applications where the lap belt runs horizontally or slightly downward from the buckle to the mounting point. Confirm your seat and mounting geometry is compatible with pull-down lap adjustment before ordering — the correct PD vs PU choice depends on your specific installation.

SFI 16.1 Certification

The 741001RQP carries SFI 16.1 certification from the SFI Foundation — the base motorsport harness performance specification. SFI 16.1 is accepted by many sanctioning bodies including NASA, SCCA, and regional HPDE organisers for their entry and intermediate competition classes. Higher-spec events and classes may require SFI 16.5 (which adds anti-submarine strap load requirements) or FIA 8853/8854 homologation. Confirm your specific series, class, and event rules to verify SFI 16.1 is accepted before purchasing. SFI certifications carry expiration dates — confirm the manufacture date tag on the harness and your series’ rules on harness age limits.

Construction — Webbing and Hardware

3-inch premium polyester webbing is used throughout — the standard width for 5-point racing harnesses, providing broad load distribution across shoulders, hips, and the sub strap under deceleration loads. Hardware includes drop-forged steel 3-bar slides and bolt-on end hardware. The double-adjustable ends can be configured for either wrap-around (looping around a tube/bar) or bolt-in (direct bolt to a threaded anchor point) mounting. Shoulder adjustment range: 25” to 72”. Lap belt adjustment range: 30” to 70”.

Installation Requirements

Shoulder belts on a 5-point harness must be anchored to a rollcage or a dedicated harness bar mounted behind the seat at the correct height and angle relative to the seat and occupant. Mounting shoulder belts to OEM seat belt anchor points or the rear seat pan without a cage or harness bar will result in incorrect shoulder belt geometry and can cause serious spinal compression injury in a frontal impact. If your vehicle does not have a rollcage or harness bar, do not install this harness. Professional installation by a qualified fabricator is strongly recommended.

For closed-course and off-road motorsport use only. NOT DOT/FMVSS 209/302 certified — not legal for street use. Requires rollcage or harness bar — do not install without one. Confirm SFI 16.1 acceptance with your sanctioning body before purchasing. Check SFI tag manufacture date against series harness age requirements. One set = one seat. Available in Black (741001RQP), Red, Blue, and Green on separate listings.

Specifications

• Brand: RaceQuip
• Part Number: 741001RQP
• Type: 5-point racing harness
• Buckle: Camlock (aluminium alloy)
• Lap Adjustment: Pull-Down (PD)
• Certification: SFI 16.1
• Webbing Width: 3 inches
• Webbing Material: Polyester
• Hardware: Drop-forged steel 3-bar slides, bolt-on ends
• Mounting: Wrap-around or bolt-in
• Shoulder Adjustment: 25” – 72”
• Lap Adjustment Range: 30” – 70”
• Colour: Black
• Weight: 7.4 lbs
